Numerical control lathe debug method
From:Taian Haishu Machinery Co.,Ltd. Updatetime:2015-12-16 14:10:47 Views：
When start the machine tools, general reference point for machine tool setting. Machine tool workpiece coordinate system should be consistent with the programming coordinate system, if the error, the possibility of turning tool and the work
Develop specification debugging action, mainly including the following:1) debugger must beat G00 speed selector switch on the F0 block, make knives at a slower rate close to the workpiece, otherwise, once the wrong knife, the cutting tool from the tool change point in G00 way very fast movement to the feed point, may be strong to collide and artifacts, let operators are confused about what to do, to eliminate danger;Instead, let the cutting tool at a slower speed is near, even if the wrong knife, operators also have plenty of time to adjust. 2) in the debug program, must take the CNC lathe is in a state of single step.The operator in the numerical control lathe after executing a program section, must check again for the next segment of right and wrong and rationality, and make adjustments accordingly. 3) nc lathe in the process of movement, the operator must always observe the change of cutter coordinates on the screen and the procedure of the sports coordinates and the coordinates of tool movement. 4) program debugging process, the operator can put a finger in the circulation on the start button, another keep a finger on the loop button, so that in times of emergency can in time to stop the execution of the program.At the same time, keep in mind the location of the emergency button, so that a rainy day. When start the machine tools, general reference point for machine tool setting.Machine tool workpiece coordinate system should be consistent with the programming coordinate system, if the error, the possibility of turning tool and the workpiece collisions is very big.In addition, the tool length compensation Settings must be correct, otherwise, either empty processing, or collision. 5) program debugging stageUsing computer simulation functions.With the development of computer technology, the expansion of the numerical control processing teaching, nc machining simulation system is becoming more and more its function improvement.Therefore can be used for preliminary examination procedure, watching the movement of the cutting tool, to determine whether there is a possible collision.Use of CNC lathe with graphic simulation and processing function.Generally more advanced numerical control lathe with graphical simulation since the processing function, before automatic processing, to avoid program error, tool collision or chuck, workpiece can be graphical simulation for the whole process, check whether the tool path is correct.
